Case WX145 - Wx 185 Models

DATA AND TECHNICAL SPECIFICATIONS
8-7
WX 185 MODELS
OUTFIT WITH PLACING BOOM
G = tyres maximum width
O = machine maximum width
mm (in)
Dipper A B C D E F G H I L M N O P Q R S T
2000
(78.73)
2650
(104.33)
450
(17.71)
1300
(51.18)
2150
(84.64)
320
(12.59)
2990
(117.71)
2520
(99.21)
3150
(124.01)
3900
(153.54)
365
(14.37)
5112
(201.25)
1010
(39.76)
2500
(98.45)
1040
(40.94)
8772
(345.35)
8802
(346.53)
1200
(47.24)
1060
(41.73)
2400
(94.48)
2650
(104.33)
450
(17.71)
1300
(51.18)
2150
(84.64)
320
(12.59)
3003
(118.23)
2520
(99.21)
3150
(124.01)
3900
(153.54)
365
(14.37)
5087
(200.27)
1010
(39.76)
2500
(98.45)
1040
(40.94)
8747
(344.36)
8777
(345.55)
1200
(47.24)
1060
(41.73)
2800
(110.23)
2650
(104.33)
450
(17.71)
1300
(51.18)
2150
(84.64)
320
(12.59)
3081
(212.29)
2520
(99.21)
3150
(124.01)
3900
(153.54)
365
(14.37)
5076
(199.84)
1010
(39.76)
2500
(98.45)
1040
(40.94)
8736
(343.96)
8766
(345.11)
1200
(47.24)
1060
(41.73)
Dipper (mm) (in)
Rear blade
(kg) (lb)
Rear stabilizers
(kg) (lb)
Front blade and
rear stabilizers
(kg) (lb)
Front and rear
stabilizers (kg) (lb)
2000 (78.73) 18680 (41096) 19230 (42306) 19810 (43582) 20270 (44594)
2400 (94.48) 18740 (41228) 19290 (42438) 19880 (43736) 20340 (44748)
2800 (110.23) 18830 (41426) 19390 (42658) 19970 (43934) 20430 (44946)
