8-1
SECTION 8
DATA AND TECHNICAL SPECIFICATIONS
DIMENSIONS - OPERATING WEIGHTS
WX 145 MODELS
OUTFIT WITH PLACING BOOM
G = tyres maximum width
O = machine maximum width
mm (in)
Dipper A B C D E F G H I L M N O P Q R S T
2000
(78.73)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
2843
(111.92)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4555
(179.33)
930
(36.61)
2500
(98.42)
1070
(42.12)
8035
(316.34)
8175
(321.85)
1175
(46.25)
1010
(39.76)
2300
(90.55)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
2891
(113.81)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4560
(179.52)
930
(36.61)
2500
(98.42)
1070
(42.12)
8040
(316.53)
8180
(322.05)
1175
(46.25)
1010
(39.76)
2600
(102.36)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
2989
(117.67)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4540
(178.74)
930
(36.61)
2500
(98.42)
1070
(42.12)
8020
(315.74)
8160
(321.26)
1175
(46.25)
1010
(39.76)
Dipper (mm) (in)
Rear blade
(kg) (lb)
Rear stabilizers
(kg) (lb)
Front blade and rear
stabilizers (kg) (lb)
2000 (78.73) 14295 (31449) 14766 (32485) 15237 (33521)
2300 (90.55) 14345 (31559) 14816 (32595) 15287 (33631)
2600 (102.36) 14395 (31669) 14866 (32705) 15337 (33741)
