INTRODUCTION, SAFETY, PLATES AND DECALS
1-31
ELECTRICAL SYSTEM
The electrical system operates on 24 V.
12 V are provided by an electronic transformer.
Electronic modules (Power Control System) ensure
that the available engine power is converted in the
best possible way into hydraulic performance.
WORKING ATTACHMENT
The working attachment is composed of positioning,
dipper and boom, bucket link and bucket. Other dig-
ging or working attachments can also be installed to
the machine.
MACHINE SIDES
The terms “right”, “left”, “front” and “rear”, when used
in this manual, indicate the sides of the machine as
seen from the operator’s seat.
1. Front side - forward
2. Rear side - backward
3. Right side
4. Left side
50
