INTRODUCTION, SAFETY, PLATES AND DECALS
1-39
Slinging points
This decal shows the slinging points for machine
handling. Never use any other slinging points than
those shown on this decal.
Hydraulic oil tank
This decal indicates the hydraulic oil tank. Make
sure that the tank indicated by this decal contains
exclusively hydraulic oil.
Hydraulic oil tank
Read this manual carefully to avoid the risk of oil
under pressure inside of the tank in case of service.
Fuel tank
This decal indicates the fuel tank. Make sure that
the tank bearing this decal contains fuel only.
Operators Manual
This decal shows the manual location. Read the
manual carefully to ensure you operate the machine
correctly.
