CONTROLS AND INSTRUMENTS
2-9
6 Push-button
Clamshell
rotation (optional)
Left clamshell rotation.
7 Push-button
Dipper/blade and
stabilizers
controls switch-
over
The controls for dipper/blade and stabilizers switch
over. (With blade/stabilizers activated the buzzer
sounds).
8 Pedal
Placing boom/
attachment
With placing boom: extension/retraction of boom
adjusting cylinder.
With hammer: hammer control.
With rotary cutter: rotary cutter control.
With shears: shears control.
Off-set digging
By depressing pedal on the upper side: the off-set
boom turns to the right.
By depressing the pedal on the bottom side: the off-
set boom turns to the left.
9 Footrest
10 Lever Lights
It selects the lights type.
Main beams signal: by pushing the lever upward.
Low beams: lever in middle position.
Main beams: by pushing the lever downward.
11 Lever Warning buzzer Acoustic signal.
12 Lever Lights Lights off.
13 Lever Lights Tail lights on.
14 Lever Lights Low beams on.
15 Lever Turn signal light Left signal light activation.
Ref. Description Operation Symbol
