CONTROLS AND INSTRUMENTS
2-13
8 Display
Attachments
Setting of hydraulic oil pressure and
of volumetric flow for the following
attachments:
- 4 different hydraulic hammers;
- 4 different rotary cutters;
- 4 different hydraulic shears.
Further options can be activated by
the dealer for use by the operator:
- degree of damping for equipment
movements and travel function;
- slewing power limiting;
- activation of “Auto Power Boost”
function;
- setting of the levelling function;
- basic setting;
- clamshell rotation;
- boom adjusting cylinder speed.
Display
Setting of display contrast and
brightness, clock, language and
measuring units.
Informations
Displays operating data of the
machine and the control system.
Machine Display of all machine data.
Ref. Description Operation Symbol
ATTACHMENTS
DISPLAY
INFORMATIONS
MACHINE
