SECTION 2
2-30
Time in hours and minutes (A) engine power level
(C).
The temperature of coolant (D) and of hydraulic oil
(E) is displayed.
All screens show the fuel level graphically.
All functions are now input by the electronics as per
table:
Start the engine. All indicator and control lights must
turn off, while the engine keeps on running.
Exception: with the upper structure holding brake,
the lamp remains on.
24
25
Operation Situation after ignition to ON
Power level 2
Auto Idle OFF
Gear shifting 1st
Floating axle blocked
Parking brake applied
Forward/reverse gear shifting idle
“Levelling” mode Active, with Memory function active
Road travel Memory
Start-up locking Memory
Creep speed OFF
Slewing brake behaviour Memory
Upper structure holding brake
ON - if set to ON when the engine is shut off
Automatic - if set to automatic or ON when the
engine is shut off
Overload indicator Memory
