— 16 —
5. Connect one PFC and three connector.
6. Fix the iron plate with twelve screws.
Terminal side
7. Connect four connectors.
Screw × 3
Screw × 3
Screw × 3
Screw × 3
15. Remove four connectors.
Connectors × 4
Connectors × 3
