— 17 —
8. Connect the connector for the battery and assemble the battery.
9. Assemble the IO Unit and fix it with three screws.
Connect four connectors and one FPC.
FPC
Screw × 3
10.Fix the iron plate with four screws.
Screw × 4
Connectors
