Casio QT-6000 Service Manual

— 20 —
5. Fix the cap to the LCD Unit.
Be careful with the position of the screw holes.
6. Fix the cap to the stand.
Be careful with the direction of the cap. The height of the screw hole on the front side should be lower.
Screw × 4
7. Let the connector through the cap and fix the LCD unit with four screws.
8. Connect the connector and fix the IO Unit with four screws.
Screw × 4
Connector

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
