Casio QT-6000 Service Manual

— 19 —
■ QT-6060D
1. Assemble the LCD Unit in the FRONT CASE with seven screws.
2. Connect the connector and fix the HINGE with five screws.
Screw × 7
Screw × 5
3. After fixing the packing to the REAR CASE, assemble the REAR CASE and the FRONT CASE.
Hooks
4. Remove the LCD unit with four screws.
Position: under both packing
Screw × 2
Screw × 2

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
