— 59 —
NO. PIN NAME I/O DESCRIPTION
110 WE3/ICIOWR O D31–D24 select signal
111 VDD Power Internal VDD
112 VSS Power Internal GND
113 SLEEP I Sleep
114 PCIGNT4 O Bus grant (host function)
115 PCIGNT3 O Bus grant (host function)
116 PCIGNT2 O Bus grant (host function)
117 PCIREQ4 I* Bus request (host function)
118 PCIREQ3/MD10 I* Bus request (host function)/mode
119 VDDQ Power IO VDD
120 VSSQ Power IO GND
121 PCIREQ2/MD9 I* Bus request (host function)/mode
122 IDSEL I Configuration device select
123 INTA O Interrupt (async)
124 PCIRST O Reset output
125 PCICLK I PCI input clock
126 PCIGNT1/REQOUT O Bus grant (host function)/bus request
127 PCIREQ1/GNTIN I Bus request (host function)/bus grant
128 SERR I/O System error
129 AD31 I/O PCI address/data/port
130 AD30 I/O PCI address/data/port
131 VDDQ Power IO VDD
132 VSSQ Power IO GND
133 AD29
134 AD28
135 AD27
I/O PCI address/data/port
136 AD26
137 AD25
138 AD24
139 C/BE3 I/O Command/byte enable
140 AD23
141 AD22 I/O PCI address/data/port
142 AD21
143 VDDQ Power IO VDD
144 VSSQ Power IO GND
145 VDD Power Internal VDD
146 VSS Power Internal GND
147 AD20
148 AD19
149 AD18 I/O PCI address/data/port
150 AD17
151 AD16
152 C/BE2 I/O Command/byte enable
153 PCIFRAME I/O Bus cycle
154 IRDY I/O Initiator ready
155 TRDY I/O Target read
156 DEVSEL I/O Device select
157 VDDQ Power IO VDD
158 VSSQ Power IO GND
159 PCISTOP I/O Transaction stop
160 PCILOCK I/O Exclusive access
161 PERR I/O Parity error
162 PAR I/O Parity
163 C/BE1 I/O Command/byte enable
164 AD15 I/O PCI address/data/port
