— 60 —
NO. PIN NAME I/O DESCRIPTION
165 AD14
166 AD13
I/O PCI address/data/port
167 AD12
168 AD11
169 VDDQ Power IO VDD
170 VSSQ Power IO GND
171 AD10
172 AD9 I/O PCI address/data/port
173 AD8
174 C/BE0 I/O Command/byte enable
175 VDD Power Internal VDD
176 VSS Power Internal GND
177 AD7
178 AD6
179 AD5
I/O PCI address/data/port
180 AD4
181 AD3
182 AD2
183 VDDQ Power I/O VDD
184 VSSQ Power I/O GND
185 AD1 I/O PCI address/data/port
186 AD0 I/O PCI address/data/port
187 IRL0 I Interrupt 0
188 IRL1 I Interrupt 1
189 IRL2 I Interrupt 2
190 IRL3 I Interrupt 3
191 VSSQ Power I/O GND
192 VDDQ Power I/O VDD
193 XTAL2 O RTC crystal resonator pin
194 EXTAL2 I RTC crystal resonator pin
195 VDD-RTC Power RTC VDD
196 VSS-RTC Power RTC GND
197 CA I Hardware standby
198 RESET I Reset
199 TRST I Reset (H-UDI)
200 MRESET I Manual reset
201 NMI I Nonmaskable interrupt
202 BACK/BSREQ O Bus acknowledge/bus request
203 BREQ/BSACK I Bus request/bus acknowledge
204 MD6/IOIS16 I Mode/IOIS16 (PCMCIA)
205 RDY I Bus ready
206 TXD O SCI data output
207 VDDQ Power IO VDD
208 VSSQ Power IO GND
209 VDD Power Internal VDD
210 VSS Power Internal GND
211 MD2/RXD2 I Mode/SCIF data input
212 RXD I SCI data input
213 TCLK I/O RTC/TMU clock
214 MD8/576 I/O Mode/SCIF data control (RTS)
215 SCK I/O SCIF clock
216 MD1/TXD2 I/O Mode/SCIF data output
217 MD0/SCK2 I/O Mode/SCIF clock
218 MD7/CTS2 I/O Mode/SCIF data control (CTS)
