ASXPRESS PLUS Rapid Sample Introduction System Operator’s Manual
Chapter 1: Introduction
11
Figure 1-4
ASXPRESS PLUS Electronics Module—Back View. Some connectors
will not be used, depending on the system configuration.
Input from Power
Supply
Power Switch
Output to
Valve/Pump
Module
Output to
Autosampler
(Serial)
Output to
Syringe Pump
(Serial)
Output to
External Pump
Input from Host PC:
Autosampler Commands
(Serial or USB)
Input from Host PC:
ASXPRESS PLUS
Configuration
(Serial or USB)
