ASXPRESS PLUS Rapid Sample Introduction System Operator’s Manual
Chapter 4: Preparing an ASX-260 or ASX-520 Autosampler
40
12 Remove the two shield pieces. Notice that the splashguard goes under the
chassis on the top and over the chassis on the bottom. When you replace the
splashguard, ensure it is oriented in this manner.
Figure 4-21 Splashguard Placement
