ASXPRESS PLUS Rapid Sample Introduction System Operator’s Manual
Chapter 4: Preparing an ASX-260 or ASX-520 Autosampler
44
Figure 4-24 Jumpers on Board in Normal Position (ASX-520)
3 On the ASX-260 board, move jumper JP2 to JP4 and leave JP3 in place (Figure
4-25 shows jumpers).
Figure 4-25 Jumpers on Board in Normal Position (ASX-260)
