ASXPRESS PLUS Rapid Sample Introduction System Operator’s Manual
Chapter 5: Preparing an ASX-1400/1600 Autosampler
56
Figure 5-2 Removing the Rinse Station Screw
3 Gently tilt the rinse station away from the autosampler the pull it out.
Figure 5-3 Removing the Rinse Station
4 Remove the tubing connecting the rinse station to the peristaltic pump.
5 Remove the tubing connecting the rinse station to the drain/waste container.
Set the rinse station and all tubing aside, as those items will not be reinstalled.
Figure 5-4 Removing the Rinse Tubing
6 Assemble the rinse intake tubing, using one of the options described later in
this chapter.
