ASXPRESS PLUS Rapid Sample Introduction System Operator’s Manual
Chapter 6: Installing the Valve/Pump Module
76
Figure 6-12 Passive Bubbling Tee in Rinse Solution Bottle
5 Connect the clear tubing of the bubbling tee to the input of the instrument's
peristaltic pump.
Figure 6-13 Fully Connected Passive Bubbling Tee
6 Makes sure that all of the tubing connections are tight.
