258 Menu List CG Drives & Automation, 01-5326-01r5
51C5 AnIn4 ValMin 0
51C6 AnIn4 FcMax Max
51C7 AnIn4 ValMax 0
51C8 AnIn4 Oper Add+
51C9 AnIn4 Filt 0.1s
51CA AnIn4 Enabl On
520 Dig Inputs 172
521 DigIn 1 RunL
522 DigIn 2 RunR
523 DigIn 3 Off
524 DigIn 4 Off
525 DigIn 5 Off
526 DigIn 6 Off
527 DigIn 7 Off
528 DigIn 8 Reset
529 B(oard)1 DigIn 1 Off
52A B(oard)1 DigIn 2 Off
52B B(oard)1 DigIn 3 Off
52C B(oard)2 DigIn 1 Off
52D B(oard)2 DigIn 2 Off
52E B(oard)2 DigIn 3 Off
52F B(oard)3 DigIn 1 Off
52G B(oard)3 DigIn 2 Off
52H B(oard)3 DigIn 3 Off
530 An Outputs 174
531 AnOut1 Fc Speed
532 AnOut1 Setup 4-20mA
533 AnOut1 Adv
5331 AnOut 1 Min 4mA
5332 AnOut 1 Max 20.0mA
5333 AnOut1Bipol -10.00-10.00 V
5334 AnOut1 FcMin Min
5335 AnOut1 VaMin 0
5336 AnOut1 FcMax Max
5337 AnOut1 VaMax 0
534 AnOut2 FC Torque
535 AnOut2 Setup 4-20mA
536 AnOut2 Advan
5361 AnOut 2 Min 4mA
5362 AnOut 2 Max 20.0mA
5363 AnOut2Bipol -10.00-10.00 V
5364 AnOut2 FcMin Min
5365 AnOut2 VaMin 0
5366 AnOut2 FcMax Max
5367 AnOut2 VaMax 0
540 Dig Outputs 178
541 DigOut 1 Ready
542 DigOut 2 Brake
550 Relays 180
551 Relay 1 Trip
552 Relay 2 Run
553 Relay 3 Off
554 B(oard)1 Relay 1 Off
555 B1 Relay 2 Off
556 B1 Relay 3 Off
557 B2 Relay 1 Off
558 B2 Relay 2 Off
559 B2 Relay 3 Off
Factory setting Customer Page
55A B3 Relay 1 Off
55B B3 Relay 2 Off
55C B3 Relay 3 Off
55D Relay Adv
55D1 Relay 1 Mode N.O
55D2 Relay 2 Mode N.O
55D3 Relay 3 Mode N.O
55D4 B1R1 Mode N.O
55D5 B1R2 Mode N.O
55D6 B1R3 Mode N.O
55D7 B2R1 Mode N.O
55D8 B2R2 Mode N.O
55D9 B2R3 Mode N.O
55DA B3R1 Mode N.O
55DB B3R2 Mode N.O
55DC B3R3 Mode N.O
560 Virtual I/Os 182
561 VIO 1 Dest Off
562 VIO 1 Source Off
563 VIO 2 Dest Off
564 VIO 2 Source Off
565 VIO 3 Dest Off
566 VIO 3 Source Off
567 VIO 4 Dest Off
568 VIO 4 Source Off
569 VIO 5 Dest Off
56A VIO 5 Source Off
56B VIO 6 Dest Off
56C VIO 6 Source Off
56D VIO 7 Dest Off
56E VIO 7 Source Off
56F VIO 8 Dest Off
56G VIO 8 Source Off
600 Logical&Timers 183
610 Comparators
611 CA1 Setup
6111 CA1 Value Speed
6112 CA1 Level HI 300rpm
6113 CA1 Level LO 200rpm
6114 CA1 Type Hysteresis
6115 CA1 Polar Unipolar
612 CA2 Setup 188
6121 CA2 Value Torque
6122 CA2 Level HI 20%
6123 CA2 Level LO 10%
6124 CA2 Type Hysteresis
6125 CA2 Polar Unipolar
613 CA3 Setup 190
6131 CA3 Value Process Val
6132 CA3 Level HI 300rpm
6133 CA3 Level LO 200rpm
6134 CA3 Type Hysteresis
6135 CA3 Polar Unipolar
614 CA4 Setup 191
6141 CA4 Value Process Err
6142 CA4 Level HI 100 rpm
6143 CA4 Level LO - 100 rpm
6144 CA4 Type Window
Factory setting Customer Page
