CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 Functional Description 93
Reference control [214]
To control the speed of the motor, the AC drive needs a
reference signal. This reference signal can be controlled by a
remote source from the installation, the keyboard of the AC
drive, or by serial or fieldbus communication. Select the
required reference control for the application in this menu
.
Communication information
Run/Stop Control [215]
This function is used to select the source for run and stop
commands. This is described on page 136.
Start/stop via analogue signals can be achieved by using
function “Stp<MinSpd [342]”.
Communication information
214 Ref control
Default: Remote
Remote 0
The reference signal comes from the
analogue inputs of the terminal strip
(terminals 1-22).
Keyboard 1
Reference is set with the + and - keys on
the Control Panel. Can only be done in
menu “Set/View reference [310]”.
Com 2
The reference is set via the serial
communication (RS 485, Fieldbus.)
See section 9.5, page 72 for further
information.
Option 3
The reference is set via an option. Only
available if the option can control the
reference value.
NOTE: If the reference is switched from Remote to
Keyboard, the last remote reference value will be the
default value for the control panel.
Modbus Instance no/DeviceNet no: 43014
Profibus slot/index 168/173
EtherCAT and CANopen index (hex) 4bc6
Profinet IO index 19398
Fieldbus format UInt
Modbus format UInt
215 Run/Stp Ctrl
Default: Remote
Remote 0
The start/stop signal comes from the digital
inputs of the terminal strip (terminals 1-22).
For settings, see menu group [330] and
[520].
Keyboard 1 Start and stop is set on the Control Panel.
Com 2
The start/stop is set via the serial
communication (RS 485, Fieldbus.) See
Fieldbus or RS232/485 option manual for
details.
Option 3 The start/stop is set via an option.
Modbus Instance no/DeviceNet no: 43015
Profibus slot/index 168/174
EtherCAT and CANopen index (hex) 4bc7
Profinet IO index 19399
Fieldbus format UInt
Modbus format UInt
