Reset Control [216]
When the AC drive is stopped due to a failure, a reset
command is required to make it possible to restart the AC
drive. Use this function to select the source of the reset
signal.
Communication information
Local/Remote key function [217]
The Toggle key on the keyboard, see section 10.2.7, page
79, has two functions and is activated in this menu. As
default the key is just set to operate as a Toggle key that
moves you easily through the menus in the toggle loop. The
second function of the key allows you to easily swap between
Local and normal operation (set up via [214] and [215]) of
the AC drive. Local mode can also be activated via a digital
input. If both [2171] and [2172] is set to Standard, the
function is disabled.
Communication information
Communication information
216 Reset Ctrl
Default: Remote
Remote 0
The command comes from the inputs of
the terminal strip (terminals 1-22).
Keyboard 1
The command comes from the
command keys of the Control Panel.
Com 2
The command comes from the serial
communication (RS 485, Fieldbus).
Remote +
Keyb
3
The command comes from the inputs of
the terminal strip (terminals 1-22) or the
keyboard.
Com +
Keyb
4
The command comes from the serial
communication (RS485, Fieldbus) or the
keyboard.
Rem+Keyb
+Com
5
The command comes from the inputs of
the terminal strip (terminals 1-22), the
keyboard or the serial communication
(RS485, Fieldbus).
Option 6
The command comes from an option.
Only available if the option can control
the reset command.
Modbus Instance no/DeviceNet no: 43016
Profibus slot/index 168/175
EtherCAT and CANopen index (hex) 4bc8
Profinet IO index 19400
Fieldbus format UInt
Modbus format UInt
2171 LocRefCtrl
Default: Standard
Standard 0 Local reference control set via [214]
Remote 1 Local reference control via remote
Keyboard 2 Local reference control via keyboard
Com 3 Local reference control via communication
Modbus Instance no/DeviceNet no: 43009
Profibus slot/index 168/168
EtherCAT and CANopen index (hex)
4bc1
Profinet IO index 19393
Fieldbus format UInt
Modbus format UInt
2172 LocRunCtrl
Default: Standard
Standard 0 Local Run/Stop control set via [215]
Remote 1 Local Run/Stop control via remote
Keyboard 2 Local Run/Stop control via keyboard
Com 3
Local Run/Stop control via
communication
Modbus Instance no/DeviceNet no: 43010
Profibus slot/index 168/169
EtherCAT and CANopen index (hex) 4bc2
Profinet IO index 19394
Fieldbus format UInt
Modbus format UInt
