Configuring Wireless Networks
300 Check Point UTM-1 Edge User Guide
6. In the Peer WLAN MAC Address field, type the WLAN MAC address of the
access point to which you want to create a WDS link.
Note: This is the MAC address of the WLAN interface, not the WAN MAC address.
To see your access point's WLAN MAC address, click Reports in the main menu,
and then click Wireless.
7. Do one of the following:
• To create a bridged WDS link:
1) In the Mode drop-down list, select Bridged.
The fields are enabled and additional fields appear.
2) Complete these fields as described in Bridged Network Fields on
page
235.
• To create a routed WDS link, do the following:
1) In the Mode drop-down list, select Enabled.
The fields are enabled.
2) In the IP Address field, type the IP address of the WDS link's default
gateway.
The WDS link must not overlap other networks.
3) In the Subnet Mask field, type the WDS link's internal network range.
8. If desired, enable or disable Hide NAT.
See Enabling/Disabling Hide NAT on page
163.
9. If desired, configure a DHCP server.
See Configuring a DHCP Server on page
164.
10. Complete the fields using the relevant information in Basic Wireless Settings
Fields on page
284.
11. To configure advanced settings, click Show Advanced Settings and complete
the fields using the relevant information in Advanced Wireless Settings Fields
on page
289.
