The UTM-1 Edge X Series and UTM-1 Edge W Series
22 Check Point UTM-1 Edge User Guide
Table 8: UTM-1 Edge X Industrial Appliance Front Panel Elements
Label Description
LAN 1-4 Local Area Network switch: Four Ethernet ports (RJ-45) used for connecting
computers or other network devices.
DMZ/
WAN2
A dedicated Ethernet port (RJ-45) used to connect a DMZ (Demilitarized Zone)
computer or network. Alternatively, can serve as a secondary WAN port or as a
VLAN trunk.
WAN Wide Area Network: An Ethernet port (RJ-45) used for connecting your broadband
modem, a wide area network router, or a network leading to the Internet.
Serial An DB-9 serial (RS-232) port used for connecting computers in order to access the
UTM-1 CLI (Command Line Interface), or for connecting an external dialup
modem.
USB Two USB 2.0 ports used for connecting USB-based printers or modems
Status
LEDs
For an explanation of the UTM-1 Edge X Industrial appliance’s status LEDs, see
the following table.
RESET A button used for rebooting the UTM-1 appliance or resetting the UTM-1
appliance to its factory defaults. You need to use a pointed object to press this
button.
• Short press. Reboots the UTM-1 appliance
• Long press (7 seconds). Resets the UTM-1 appliance to its factory
defaults, and resets your firmware to the version that shipped with the
UTM-1 appliance. This results in the loss of all security services and
passwords and reverting to the factory default firmware. You will have
to re-configure your UTM-1 appliance.
Do not reset the unit without consulting your system administrator.
24V 0.6A A power jack used for supplying 24V DC power to the unit. Connect the supplied
24V DC connector plug to this jack.
