The UTM-1 Edge X Series and UTM-1 Edge W Series
34 Check Point UTM-1 Edge User Guide
Getting to Know Your UTM-1 Edge W ADSL Appliance
Package Contents
The UTM-1 Edge W ADSL package includes the following:
• UTM-1 Edge W ADSL Internet Security Appliance
• Power supply
• CAT5 Straight-through Ethernet cable
• Getting Started Guide
• Documentation CDROM
• Wall mounting kit
• RS232 serial adaptor (RJ45 to DB9)
• Two antennas
• USB extension cable
• RJ11 telephone cable
Network Requirements
• 10BaseT or 100BaseT Network Interface Card installed on each computer
• CAT 5 STP (Category 5 Shielded Twisted Pair) Straight Through Ethernet cable
for each attached device
• An ADSL line suitable for your appliance model:
• For Annex A ADSL models, an ADSL over POTS line (regular telephone
line)
• For Annex B ADSL models, an ADSL over ISDN line (digital line)
• A splitter with a micro-filter, installed on all the jacks connected to the same
phone line
