Industry-Standard Wiring Plans C-283
For smaller numbers of wires, such as wires for an individual telephone station or terminal, you may
use a second color code scheme. Table C-2 lists this color code and the usual correspondence with
the paired-wire color code. The alternate color code is included because sometimes the station wire
uses the first three pairs of the standard color code (white-blue, blue-white, and so on), while other
times it uses the six alternate colored wires.
Table C-2 Second Color Code Scheme for Smaller Numbers of Wires
Pair Number Wire Number Solid Color Stripe Color Alternate Color Pin Number
1 1 White Blue Green 4
12 BlueWhiteRed 3
2 1 White Orange Black 2
2 2 Orange White Yellow 5
3 1 White Green White 1
32 GreenWhiteBlue 6
