Chapter 4 Front Panel Operation
72
Menu Item
Description
Parameters
CA Ctl
Sets how the conditional access will attempt to
descramble the scrambled programs. The
behavior of this setting is different between
PowerVu streams and those that require a
CAM.
For PowerVu streams:
Std - In standard mode, if
a program is not
authorized, even if some
services are not scrambled,
the whole program will
not be authorized.
Open - In open mode, if a
program is not authorized,
services in the program
that are not scrambled will
still be available.
For Non-PowerVu (CAM)
streams:
Std - In standard mode, if
a program’s CA system is
not supported by the
CAM, the channel is not
authorized.
Open - In open mode, all
the program’s CA systems
are validated by the CAM.
The channel is always
authorized.
Select
Sets the method to determine which available
MPEG over IP stream, for each data port, to
use as a transport input.
UserCfg - User can select
one of the available MPEG
over IP streams for Data1
and/or Data2 ports.
SW Map - Pre-defined
software algorithm is used
to determine the MPEG
over IP streams for Data1
and Data 2 ports.
isMulticast
Select Yes to listen to MPEG over IP streams
sent to a specific multicast IP address (group).
Otherwise, select No to listen to the unicast
MPEG over IP streams sent to the IP addresses
of the Data1 and Data2 ports.
Yes or No
IP Address
If isMulticast is set to Yes, enter the multicast
IP address.
Valid multicast IP address
