Setup Menu
73
Menu Item
Description
Parameters
FEC
Type of expected FEC streams for the decoder
to analyze and use.
None - All FEC streams
are dropped.
1D - Column stream is
expected.
2D - Column and row
streams are expected.
Src Filter
Select the source (host) filtering mode.
None - All streams sent to
a specific destination IP
address (multicast or
unicast) and destination
TS and FEC UDP ports are
received, without source
restrictions.
White List - The unit will
only receive streams from
the defined list of
hosts/servers (Idx and IP
Address). It will reject the
streams received from the
host/servers that are not
defined on the list.
Black List - The unit will
reject the streams received
from the defined list of
hosts/servers (Idx and IP
Address).
TS UDP
The transport stream UDP port number. For
RTP port, enter an even port number. For UDP
port, you can enter an even or odd port
number.
Note: FEC is only supported for RTP transport
streams.
1 to 65534
FEC1 UDP
If FEC is set to 1D or 2D, set the FEC
destination UDP port number of the column
FEC stream.
2 to 65534
FEC2 UDP
If FEC is set to 2D, in addition to entering the
port number of the column FEC stream, enter
the FEC destination UDP port number of the
row FEC stream.
2 to 65534
Source IP Select
Displays the detected host.
Valid host IP address or
0.0.0.0 if none is found.
