Configuring Cisco IOS Configuration Engine
Information About Configuring Cisco IOS Configuration Engine
Information About Configuring Cisco IOS Configuration Engine
Cisco Configuration Engine is network management software that acts as a configuration service for automating the
deployment and management of network devices and services (see Figure 5 on page 81). Each Cisco Configuration
Engine service manages a group of Cisco devices (switches and routers) and the services that they deliver, storing their
configurations and delivering them as needed. Cisco Configuration Engine automates initial configurations and
configuration updates by generating device-specific configuration changes, sending them to the device, executing the
configuration change, and logging the results.
Cisco Configuration Engine supports standalone and server modes and has these CNS components:
 Configuration service (web server, file manager, and namespace mapping server)
 Event service (event gateway)
 Data service directory (data models and schema)
In standalone mode, Cisco Configuration Engine supports an embedded directory service. In this mode, no external
directory or other data store is required. In server mode, Cisco Configuration Engine supports a user-defined external
directory.
Device Required Configuration
Access switch Factory default (no configuration file)
Distribution switch  IP helper address
 Enable DHCP relay agent
 IP routing (if used as default gateway)
DHCP server  IP address assignment
 TFTP server IP address
 Path to bootstrap configuration file on the TFTP server
 Default gateway IP address
TFTP server  A bootstrap configuration file that includes the CNS configuration
commands that enable the switch to communicate with the
Configuration Engine
 The switch configured to use either the switch MAC address or the serial
number (instead of the default hostname) to generate the ConfigID and
EventID
 The CNS event agent configured to push the configuration file to the
switch
CNS Configuration Engine One or more templates for each type of device, with the ConfigID of the
device mapped to the template

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
