Cisco NCS 2000 series Troubleshoot Manual

Table 1: DWDM Card Facility Loopback Behavior
Facility Loopback SignalCard/Port
BridgedTXP_MR_10E/TXP_MR_10E_C/TXP_MR_10E_L client ports
TerminatedTXP_MR_10E/TXP_MR_10E_C/TXP_MR_10E_L trunk ports
TerminatedTXP_MR_2.5G/TXPP_MR_2.5G client ports
TerminatedTXP_MR_2.5G/TXPP_MR_2.5G trunk ports
BridgedMXP_2.5G_10E_C/MXP_2.5G_10E_L client ports
TerminatedMXP_2.5G_10E_C/MXP_2.5G_10E_L trunk ports
TerminatedMXP_MR_10DME client ports
TerminatedMXP_MR_10DME trunk ports
BridgedMXP_MR_2.5G/MXPP_MR_2.5G client ports
TerminatedMXP_MR_2.5G/MXPP_MR_2.5G trunk ports
TerminatedGE_XP/10GE_XP client ports
TerminatedGE_XP/10GE_XP trunk ports
BridgedADM-10G client ports
TerminatedADM-10G trunk ports
Bridged40G-MXP-C/40E-MXP-C/40ME-MXP-C client ports
Bridged40G-MXP-C/40E-MXP-C/40ME-MXP-C trunk ports
Bridged40E-TXP-C/40ME-TXP-C client ports
Bridged40E-TXP-C/40ME-TXP-C trunk ports
TerminatedAR_XP/AR_MXP client ports
TerminatedAR_XP/AR_MXP trunk ports
The loopback itself is listed in the Conditions window. For example, the window would list the
LPBKFACILITY condition for a tested port. (The Alarms window would show the AS-MT condition which
means that alarms are suppressed on the facility during loopback unless the default is set to alarm for loopback
while in AS-MT.)
With a client-side SONET or ANSI facility loopback, the client port service state is OOS-MA,LPBK & MT.
However, any remaining client and trunk ports can be in any other service state. For SONET or ANSI cards
in a trunk-side facility loopback, the trunk port service state is OOS-MA,LPBK & MT and the remaining
client and trunk ports can be in any other service state.
With a client-side SDH or ESTI facility loopback, the client port is in the Locked-enabled,maintenance &
loopback service state. However, the remaining client and trunk ports can be in any other service state. For
MXP and TXP cards in a SDH or ETSI trunk-side facility loopback, the trunk port is in the
Cisco NCS 2000 series Troubleshooting Guide, Release 11.0
4
General Troubleshooting
Card Behavior
