Configuring the SPA932 Attendant Console
SPA932 Features
174 Cisco SPA and Wireless IP Phone Administration Guide
9
SPA932 Features
SPA932 features include:
• 32 programmable speed-dial or direct station select (DSS) buttons/LEDs
• Three-color LEDs (red, green, and orange)
• Support for BroadSoft Busy Lamp
• Support for Asterisk Line Monitoring
• Illuminated line status monitoring (Idle, Ringing, Busy, Null, or Registration
Error)
• One-touch Call Transfer—Incoming calls can be immediately transferred to
the target destination by pressing a button/key as assigned on the
SPA932.
The following table describes SPA932 ports and LEDs.
.
Port/LED Meaning
AUX IN Connects to the phone.
AUX OUT Connects to a second SPA932 unit (optional)
Green Idle
Red In-use
Blinking Red Ringing
Orange Solid: not registered. Blinking: configuration error.
Off Not configured
