Getting Started
Using the Web Administration User Interface
28 Cisco SPA and Wireless IP Phone Administration Guide
2
Using the Web Administration Tabs
The following graphics show all Admin Login advanced tabs that appear on your
web UI pages. When viewing in User Login or basic view, fewer tabs are visible.
Each tab contains different parameters. Some tasks require you to set parameters
in different tabs.
For field reference about each parameter available on the web UI, see
Appendix B, “SPA and Wireless IP Phone Field Reference.”
Roadmap to Web UI Features
The following tables provide a roadmap to features available on the web UI.
To perform these tasks... On the web UI, click the ...
View phone, extension, and line/call information
such, including:
• DHCP, current IP address, DNS addresses
• Software and hardware versions
• Broadcast, RTP, and SIP information
• Registration state
• Packets sent, received, lost, and other
information
Info tab
See “Viewing Phone
Information” section on
page 31.
Configure system-level parameters, including
network and debug parameters. To:
• Enable the web UI and web administrator
access
• Set the Internet connection type to DHCP
• Configure the syslog and debug servers
• Enable VLAN and CDP
System tab
See Chapter 6, “Configuring
Security, Quality, and Network
Features.”
