Configuring the SPA932 Attendant Console
Setting Up the SPA932 Attendant Console
Cisco SPA and Wireless IP Phone Administration Guide 177
9
STEP 4 On the Busy Lamp Field page, move users that need to be monitored from the
Available Users column to the Monitored Users column.
STEP 5 Click the Add (or Add All) button to move each user to the Monitored Users
column. The Directory Number (DN) associated with each user account when it is
created on the BroadSoft Server is shown in parenthesis in the Monitored Users
list. You use this DN to identify the specific phone assigned to each key on the
SPA932.
STEP 6 Save and enable your configuration changes on the BroadSoft server.
See also the “Configuring BroadSoft Busy Lamp Field Auto-Configuration
(SPA525G)” section on page 182.
Configuring the Asterisk Server for the SPA932
To configure the Asterisk server to allow the SPA932 to register for BLF
monitoring:
STEP 1 Add a context in the extensions.conf file.
STEP 2 Add a Subscribecontext command to point to the context in the sip.conf file.
STEP 3 Configure the SPA932 to register with the Asterisk server (see “Configuring the
SPA932” section on page 178.
The following example context uses “home” for extension 3500. This is entered in
the file extensions.conf:
[home]
exten => 3500,1,Dial(SIP/3500)
exten => 3500,hint,SIP/3500
exten => 3500,2,Voicemail,u3500
exten =>3500,1,3,hangup
...
(continued)
