SPA and Wireless IP Phone Field Reference
Phone Tab
Cisco SPA and Wireless IP Phone Administration Guide 249
B
Lightweight Directory Access Protocol (LDAP) Corporate
Directory Search
NOTE Does not apply to the WIP310.
If using Active Directory with authentication set to MD5, you must first configure
the following:
• Click the System tab. In the Optional Network Configuration section, under
Primary DNS, enter the IP address of the DNS server.
• In the Optional Network Configuration section, under Domain, enter the
LDAP domain.
Parameter Description
LDAP Dir Enable Choose yes to enable LDAP.
LDAP Corp Dir Name Enter a free-form text name, such as “Corporate
Directory.”
LDAP Server Enter a fully qualified domain name or IP address of
LDAP server, in the following format:
nnn.nnn.nnn.nnn
LDAP Auth Method Select the authentication method that the LDAP
server requires. Choices are:
• None—No authentication is used between the
client and the server.
• Simple—The client sends its fully-qualified
domain name and password to the LDAP server.
May present security issues.
• Digest-MD5—The LDAP server sends
authentication options and a token to the client.
The client returns an encrypted response that is
decrypted and verified by the server.
