Customizing Cisco SPA and Wireless IP Phones
Configuring Phone Features
Cisco SPA and Wireless IP Phone Administration Guide 67
4
You can configure the characteristics of each ring tone using a Ring Tone script. In
a Ring Tone script, you can assign a name for the ring tone, and specify:
• Name (n)—Ring tone name, such as Classic, Simple, and Office
• Waveform (w)—1, 2, 3, or 4
• Cadence (c)—1, 2, 3, 4, or 5
You can also download one of two available ring tones (user ring tone 1 or 2) using
TFTP:
http://phone_ip_addr/ringtone1?[url]
• Where the URL syntax is tftp:
//host[:port]/path
.
• The default host is the TFTP host.
• Port is optional. The default port is 69.
• The link is case sensitive.
On the SPA phones, user-downloaded ring tones are labeled User 1 and User 2 in
the choices for the Default Ring. On the phone ring tone menu, the User 1 and 2
choices are replaced by the corresponding name of the ring tone. “Not Installed”
appears if the user ring tone slots are not used.
For ring tone User 1 and User2, the cadence is fixed with the on-time equals to the
duration of the ring tone file and off-time equals to four seconds. The total ring
duration is fixed at 60 seconds. The user ring tone names displayed on the phone
LCD are derived from the ring tone file header file.
The phone does not require rebooting after downloading a ring tone.
To remove the User 1 ring tone from the phone, set the
path
to delete, as follows:
http://phone_ip_addr/ringtone1?/delete
Configuring On-Demand Ring Tones (SPA525G)
The SPA525G supports on-demand ring tones, which means that ring tones are
downloaded and played from a TFTP server when a call comes in. To configure:
STEP 1 Log in to the web administration interface.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Phone tab.
