ComAp InteliCompact NT

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
35
Caterpillar DVR
18VAC
From
generator
OUT1
OCOM
iG-
AVRi
230/400VAC
0VAC
AVRI
AO GND
AO GND
AVRI
7
45
IG-
AVRi
TRANS
Pin 44 on DVR – PF regulation directly from DVR is not connected.
AVRi trim to 25%
Volt/PF ctrl:
AVR Bias = 50%
Caterpillar VR6, VR3F
18VAC
From
generator
OUT1
OCOM
iG-
AVRi
230/400VAC
0VAC
AVRI
AO GND
AO GND
AVRI
TR5
TR6
TR7
IG-
AVRi
TRANS
For VR3F link 4-7 has to be removed.
AVRi trim to minimum counter
clockwise.
Volt/PF ctrl:
AVR Bias
Caterpillar VR6-B
18VAC
From
generator
OUT1
OUT2
iG-
AVRi
230/400VAC
0VAC
AVRI
AO GND
4
7
2
3
AVRI
AO GND
IG-
AVRi
TRANS
AVRi trim to minimum counter
clockwise.
Volt/PF ctrl:
AVR Bias = 0%
Voltage range (-2 V; 2 V)
Basler
Basler: APR 63-5, AEC 63-7, KR-FX, KR-FFX
18VAC
From
generator
OUT1
OCOM
iG-
AVRi
230/400VAC
0VAC
AVRI
AO GND
AO GND
AVRI
7
6
IG-
AVRi
TRANS
AVRi output is connected instead of external resistor for voltage adjusting.
AVRi trim to minimum counter
clockwise.
Volt/PF ctrl:
AVR Bias = 50%
Basler: DECS 100
18VAC
From
generator
OUT1
OUT2
iG-
AVRi
230/400VAC
0VAC
AVRI
AO GND
B
A
AVRI
AO GND
IG-
AVRi
TRANS
AVRi output is connected instead of external resistor for voltage adjusting.
AVRi trim to minimum counter
clockwise.
Volt/PF ctrl:
AVR Bias = 50%
