ComAp InteliCompact NT Reference Guide

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
46
Caterpillar
19
9
Caterpillar
PEEC
SG +
AO COM
PWM
Pay attention to the connector and jumper orientation.
1
2
Caterpillar
Signal
Converter
SG +
AO COM
VoutR
67k7
Sync/Load Ctrl:
Speed Gov Bias = 5.10 V
SpeedGovChar =
POSITIVE
SpeedGovLowLim = 0 V
SpeedGovHiLim = 10 V
10
12
Caterpillar
ADEM
SG +
AO COM
PWM
MTU
36
8
MTU MDEC
2000, 4000
SG +
AO COM
Vout
Sync/Load Ctrl:
Speed Gov Bias = 4.90 V
SpeedGovChar =
POSITIVE
SpeedGovLowLim = 0 V
SpeedGovHiLim = 10 V
Deutz
23
24
DEUTZ
BF6M
SG +
AO COM
Vout
PLUG F
17
21
Opened for
0% droop
Sync/Load Ctrl:
Speed Gov Bias = 2.50 V
SpeedGovChar =
POSITIVE
SpeedGovLowLim = 0.5 V
SpeedGovHiLim = 4.5 V
Pay attention to the connector and jumper orientation.
