Cyan Z77 - Figure 86: MSE-1482 Transparent Line Functionality - Route Diversity

Cyan Z-Series Engineering and Planning Guide Release 5.0
Page 166 © 2013 Cyan, Inc. – All Rights Reserved. 700-0023-05-00 Rev. 1
Protection provided by ADM
matching line interfaces:
OC-3/STM-1 -- OC-3/STM-1
OC-12/STM-4 -- OC-12/STM-4
OC-48/STM-16 -- OC-48/STM-16
MSE-1482
MSE-1482
MSE-1482
MSE-1482
ADM
Cyan Z-Series
Shelf
Cyan Z-Series
Shelf
OTU-2
Tunneled DCC
Ring or Other Route Diverse Configuration
Cyan Z-Series
Network
Figure 86: MSE-1482 Transparent Line Functionality - Route Diversity
