• Link budget 8 to 20 dB (up to 80 km with 0.25 dB/km)
• Fiber types supported: NSDF (G.652), NZ-DSF (G.655)
• Transponding and muxponding in conjunction with SFT modules
2.9.3 Management
• DCN connectivity
• A – Z circuit provisioning using Planet Operate
• SNMP v2
• CLI
• TL1
2.9.4 Physical
• Module dimensions:
 Depth: 11.6" / 295 mm
 Width: 1.2" / 30.5 mm
 Height: 13.8" / 350 mm
• Weight: 4 lbs / 1.8 kg
2.9.5 Power
• Dual -48V DC power feeds to module slots
• LAC-8 power consumption: 10 watts typical, 12 watts maximum
2.9.6 Environmental
• +32°F to +122°F / 0°C to +50°C operating temperature
• 5% to 85% operating relative humidity (non-condensing)
• 13,000 feet (4,000 m) altitude
2.9.7 LAC-8 Wavelength Assignments
LAC-8 Wavelength Assignment
LAC-8
Wavelength
(nm)
1 1470
2 1490
3 1510
4 1530
5 1550
6 1570
7 1590
8 1610
