1.3.1 Z77 Card Installation Guidelines
Z77 slot restrictions and line card placement guidelines are shown in the table below. Note that slots 1 and 2
are reserved for the BOSS/BOSS2 cards and are not shown in the table. Card pairs, where applicable, can be
installed in slots 3/4, 5/6, 7/8, 9/10, 11/12, 13/14, and 15/16.
Line Cards
Slots *
3 4 5 6 7 8 9 10 11 12 13 14 15 16
2.5G-LME4 X X X X X X X X X X X X X X
DTM-8 X X X X X X X X X X X X X X
DTM-8G X X X X X X X X X X X X X X
DTM-100G X X X X X X X X X X X X X X
LAD-4 X X X X X X X X X X X X X X
LAD-4A X X X X X X X X X X X X X X
LAD-8 X X X X X X X X X X X X X X
LAD-8A X X X X X X X X X X X X X X
LAD-8E X X X X X X X X X X X X X X
LAD-8i X X X X X X X X X X X X X X
LAD-8X X X X X X X X X X X X X X X
LAD-40 X X X X X X X X X X X X X X
LAD-40E X X X X X X X X X X X X X X
LAC-8 X X X X X X X X X X X X X X
PME-412 X X X X X X X X X X X X X X
PME-216i X X X X X X X X X X X X X X
TSW-10G10 X X X X X X X X X X X X X X
PSW-10G10 X X X X X X X X X X X X X X
PSW-618 X X X X X X X X X X X X X X
SFT-8 X X X X X X X X X X X X X X
SFT-10G16 X X X X X X X X X X X X X X
MSE-1482 X X X X X X X X X X X X X X
FLX-216i X X X X X X X X X X X X X X
WSS-402 X X X X X X X X X X X X X X
WSS-404 X X X X X X X X X X X X X X
* Shading indicates paired slots for applicable line cards.
Individual Z-Series line cards are described in Z-Series Line Cards, Modules, and Optics starting on page 47.
For information on recommended slot assignments for LAD modules, WSS modules, and service card pairs, see
Best Practices for Network Configurations starting on page 199.
All modules are hot-swappable.
