700-0023-05-00 Rev. 1 © 2013 Cyan, Inc. – All Rights Reserved. Page 181
Chapter 6:
Management Network
Configuration Guidelines
This section describes the Cyan Data Communications Network (DCN) architecture. It provides use cases
for deploying Cyan Z-Series nodes with the Planet Operate in an IP DCN network. The use cases provide
recommendations for configuring external routers.
In This Chapter
Single Physical LAN ............................................................................. 182
Multiple Physical LANs ........................................................................ 185
Multiple Physical LANs and the Same IP Sub-Network ...................... 192
Network and Host Routes…………………………………………….198
Management Overview
The Cyan DCN architecture is based on the ITU-T G.7712 standard supporting IP-based communication
with OSPF routing. All Cyan nodes require a unique IP address.
Note: Each Cyan node in the network must have a unique IP address provisioned. When
commissioning Cyan equipment the following IP addresses are not supported:
• 192.168.0.1 – 192.168.0.255 Subnet 255.255.255.0
• 192.168.1.0 – 192.168.1.255 Subnet 255.255.255.0
• 192.168.2.0 – 192.168.2.255 Subnet 255.255.255.0
• 192.168.3.0 – 192.168.3.255 Subnet 255.255.255.0
• 172.16.0.1 – 172.16.0.255 Subnet 255.255.255.0
169.254.0.1 – 169.254.254.254 Subnet 255.255.255.0
Cyan Z-Series and Cyan L-AMP nodes can be placed in various configurations based on how they are
physically connected and how they are logically divided into IP sub-networks. Physical connectivity falls
into one of the following scenarios:
• All Cyan nodes are connected directly using the same physical LAN segment.
• Cyan nodes are separated into different physical LAN segments.
