Cyan Z-Series Engineering and Planning Guide Release 5.0
700-0023-05-00 Rev. 1 © 2013 Cyan, Inc. – All Rights Reserved. Page 81
Note: Cyan single-fiber XFP and SFP+ transceiver modules are designed specifically for
datacomm applications. These transceiver modules do not support OTU2 signal types.
2.5.8 Management
• G.709 and OTN support on all DWDM interfaces
• A – Z circuit provisioning using Planet Operate
• SNMP v2
• CLI and TL1
• EMS-based integration creates end-to-end OAM regardless of topology or packet/OTN mixed links
2.5.9 Physical
• Module dimensions:
Depth: 11.6" / 295 mm
Width: 1.2" / 30.5 mm
Height: 13.8" / 350 mm
• Weight: 4.25 lbs / 1.93 kg
2.5.10 Power
• Dual -48V DC power feeds to module slots (Z22 -48V DC model, Z33, and Z77)
• Dual +24V DC power feeds to module slots (Z22 +24V DC model)
• Power consumption: 67 watts typical, 97 watts maximum
Note: This reflects the typical power requirements of 2 XFP and 16 SFP transceivers.
2.5.11 Environmental
• -40°F to +149°F / -40°C to +65°C operating temperature
• 5% to 85% operating relative humidity (non-condensing)
• 13,000 feet (4,000 m) altitude
2.5.12 Compliance / Safety
• NEBS 3 Certified (GR-63 CORE, GR-1089)
• UL/CSA Listed
• UE/CE-Marked: EN 60950, EN 55022, EN 6 1000, ETSI EN 300 386 V.1.3.3
• CB Scheme Certified 60950
• FCC, Subpart B, Part 15, Class A
• RoHS compliant
