Cyan Z-Series Engineering and Planning Guide Release 5.0
700-0023-05-00 Rev. 1 © 2013 Cyan, Inc. – All Rights Reserved. Page 45
1.4.3 L-AMP OSC Specifications
Frequency:
198.5 THz 1510nm
Data Format:
100Base-FX Ethernet
Maximum TX Power:
5 dBm
Minimum TX Power:
-1 dBm
Maximum RX Power:
-3 dBm
Minimum RX Power:
-33 dBm
OSC Link Budget:
8 – 32 dB
Note: If you are using CyOS 3.x, RX power at -10 dBm or higher will raise a High RX power
alarm. If you are using CyOS 4.0, RX power at -10 dBm or higher does not raise a High RX power
alarm, but an "Out of Range – High" notification will be displayed in Planet Operate in the
Transport Resources tab for the L-AMP OSC.
1.4.4 L-AMP Features
• All access on front panel
• 1
RU x 19 inches wide (with mounting brackets for 23-inch racks)
• 40ch + OSC: 80 km amplifier
• Remotely managed via OSC
• Craft interface
• Management LAN available for other devices
• Four alarm input/output contacts
• Mid-stage DCM access and monitor ports
• Redundant power
• Hot swap fan module (3 x fans)
• Managed through Planet Operate, CLI, TL1, and SNMP v2
1.4.5 L-AMP Applications
• Extended optical reach of DWDM transport
• Management LAN and alarm extension
1.4.6 L-AMP Physical
• Height: 1.735" (44.069 mm)
• Width: 18.31" (465.074 mm)
• Depth: 11.98" (304.29 mm)
• Weight: 10 lbs (4.55 kg)
