Cyan Z77 - Compliance; Safety; LAD-2 G 1550 Nm Add;Drop Port; LAD-2 P and LAD-8 I 1310 Nm Add;Drop Port

Cyan Z-Series Engineering and Planning Guide Release 5.0
Page 60 © 2013 Cyan, Inc. – All Rights Reserved. 700-0023-05-00 Rev. 1
2.1.8 LAD-2P and LAD-8i 1310nm Add/Drop Port
LAD-2P LAD-8i
Wavelength range
1270nm – 1350nm 1270nm – 1350nm
Mux-Demux pair insertion loss
2.4 dB maximum 3.0 dB maximum
2.1.9 LAD-2G 1550nm Add/Drop Port
LAD-2G
Wavelength range
1530.33nm – 1565nm
Mux-Demux pair insertion loss
3.6 dB maximum
2.1.10 Compliance / Safety
• NEBS 3 Certified (GR-63 CORE, GR-1089)
• UL/CSA Listed
• UE/CE-Marked: EN 60950, EN 55022, EN 6 1000, ETSI EN 300 386 V.1.3.3
• CB Scheme Certified 60950
• FCC, Subpart B, Part 15, Class A
• RoHS compliant
