2.1.5 Power
• Dual -48V DC power feeds to LAD module slots
Power Consumption
Module Watts – Typical Watts – Maximum
LAD-4 10 12
LAD-4A 15 21
LAD-8 10 12
LAD-8i 10 12
LAD-8A 15 21
LAD-8E 30 35
LAD-8X 30 35
LAD-40 10 12
LAD-40E 28 30
Note: The LAD-2P and LAD-2G modules are powered via the shelf CEMi module.
Note: The AWG-40 module used in conjunction with the LAD-40 and LAD-40E modules is a
passive device.
2.1.6 Environmental
• Operating Temperature
 LAD-4, LAD-4A, LAD-8, LAD-8A, LAD-8X: +32°F to +122°F / 0°C to +50°C
 LAD-40, LAD-40E: +32°F to +131°F / 0°C to +55°C
 LAD-8i, LAD-2P, LAD-2G: I-Temp -40°F to +149°F / -40°C to +65°C
• 5% to 85% operating relative humidity (non-condensing)
• 13,000 feet (4,000 m) altitude
2.1.7 LAD Module Wavelength Assignments
LAD-2G Add/Drop Ports
LAD-2G
Wavelength
(nm)
ITU Channel
1 1529.55 60
2 1528.77 61
