Cyan Z-Series Engineering and Planning Guide Release 5.0
Page 176 © 2013 Cyan, Inc. – All Rights Reserved. 700-0023-05-00 Rev. 1
5.2 Cyan Z33 Power
The following table shows the typical and maximum power consumption for the Z33 system.
Equipment
Typical
Power
Maximum
Power
Shelf with Fans 30W 155W
CEMi 8W 10W
LAD-4/8/8i/40 10W 12W
LAD-4/8A 15W 21W
LAD-8E/8X 30W 35W
LAD-40E 28W 30W
DTM-8 75W 96W
DTM-8G 85W 95W
DTM-100G 180W 200W
2.5G-LME4 55W 65W
PME-412 88W 126W
PME-216i 67W 97W
LAC-8 10W 12W
MSE-1482 90W 100W
FLX-216i 100W 127W
SFT-8 45W 50W
SFT-10G16 75W 80W
WSS-402 50W 65W
WSS-404 60W 65W
Depending on your configuration, the Z33 shelf may require special equipment room cooling. Refer to
CyPlan for heat dissipation data or contact CyTAC for additional information.
