2.4.5 Optical Transport
• Up to 2 10GbE rings per module, or
• Up to 2 10G OTU2 (10.709 Gbps) trunk interfaces per module, or
• Up to 2 10G OTU2e (11.0957 Gbps) trunk interfaces per module, or
• Up to 2 OTU1e (11.0491 Gbps) trunk interfaces per module
• G.975 Generic forward error correction (GFEC)
• Enhanced G.975.1/App.4 (enhanced FEC)
2.4.6 Interfaces
• Up to 4 10GbE LAN/WAN (XFP)
• Up to 2 10G OTU2 (XFP)
• Up to 2 10G OTU2e (XFP)
• Up to 2 10G OTU1e (XFP)
• Up to 12 GbE (SFP)
• Up to 2 10GbE backplane interfaces for module to module Ethernet switching and protection
• Physical: Front access, fixed wavelength XFP optics
Note: Recently introduced Cyan single-fiber XFP and SFP+ transceiver modules are designed
specifically for datacomm applications. These transceiver modules do not support OTU2 signal types.
Note: Configuring 10GE WAN signal types for PME-412 ports 3 and 4 are planned for a future release.
2.4.7 Management
• G.709 and OTN support on all DWDM interfaces
• A – Z circuit provisioning using Planet Operate
• SNMP v2
• CLI
• TL1
2.4.8 Physical
• Module dimensions:
 Depth: 11.6" / 295 mm
 Width: 1.2" / 30.5 mm
 Height: 13.8" / 350 mm
• Weight: 4 lbs / 1.8 kg
