1.4.7 L-AMP Power
Feeds:
4 2-A & 2-B
Voltage Range:
-40 to -60 Vdc Guaranteed Operation
Max Voltage:
-/+100 Vdc Non-operational, no damage
Power
Consumption:
50 W
80 W
Typical
Maximum
Max Current:
2 Amps
1.4.8 L-AMP Compliance
• NEBS 3 Certified (GR-63 CORE, GR-1089)
• UL/CSA Listed
• UE/CE-Marked: EN 60950, EN 55022, EN 6 1000, ETSI EN 300 386 V.1.3.3
• CB Scheme Certified 60950
• FCC, Subpart B, Part 15, Class A
• RoHS compliant
