Cyan Z77 - Chapter 5: System Power; Cyan Z22 Power

700-0023-05-00 Rev. 1 © 2013 Cyan, Inc. – All Rights Reserved. Page 175
Chapter 5: System Power
This section provides system power information for Cyan Z-Series equipment.
Note: Use Planet Design as a guideline based on the total configured system current draw.
You must size fuses according to NEC standards or local site practice.
In This Chapter
Cyan Z22 Power .................................................................................... 175
Cyan Z33 Power .................................................................................... 176
Cyan Z77 Power .................................................................................... 177
Fuses ...................................................................................................... 177
Z77 Fuse Positions and DC Feeds ......................................................... 178
5.1 Cyan Z22 Power
The following table shows the typical and maximum power consumption for the Z22 system.
Equipment
Typical
Power
Maximum
Power
Shelf with Fans 15W 50W
CEMi
8W
10W
PME-216i (+24V)
67W
97W
PME-216i (-48V)
67W
97W
PME-412
88W
126W
MSE-1482
90W
100W
FLX-216i
100W
127W
SFT-8
45W
50W
SFT-10G16
75W
80W
DTM-8
75W
96W
DTM-100G
180W
200W
2.5G-LME4
55W
65W
WSS-402
50W
65W
WSS-404
60W
65W
The LAD 2P and LAD-2G in-chassis modules are powered via the CEMi module with negligible power
consumption.
