Cyan Z-Series Engineering and Planning Guide Release 5.0
Page 26 © 2013 Cyan, Inc. – All Rights Reserved. 700-0023-05-00 Rev. 1
-48V Z22 Shelf
Line Cards
Slots
A B 1 2
CEMi X X
LAD-2P or LAD-2G X
PME-216i (-48V)
X X
PME-412 X X
MSE-1482 X X
SFT-8
X X
2.5G-LME4 X X
SFT-10G16 X X
DTM-8 / DTM-8G
X X
DTM-100G X X
FLX-216i X X
WSS-402
X X
WSS-404 X X
Important! – At least one Z-Series line card must be installed in slots 1 and/or 2 of the -
Z22 shelf to act as the shelf manager.
Note: A dual-slot DTM-100G line card installed in slots 1 and 2 does NOT provide shelf manager
redundancy.
1.1.3 CEMi Controller Card: +24 Volt
The CEMi +24V model is identical in function to the -48V CEMi controller card, but is designed to operate
in 24-volt applications supported by the Z22 +24V shelf model. Voltage range for the +24 volt CEMi card is
18 to 30 Vdc.
For CEMi controller card feature details and specifications, see Common Equipment Module (CEMi)
starting on page 33.
1.1.4 Z22 Physical
• Height: 3.5" / 88.9 mm (2 RU)
• Width: 19.00" / 483 mm
• Depth: 14.85" / 377 mm
• Weight: 15 lbs. / 6.8 kg (with 2 CEMi cards and fan tray)
• Operating temperature: -40°F to +149°F / -40°C to +65°C (I-Temp)
