Cyan Z-Series Engineering and Planning Guide Release 5.0
700-0023-05-00 Rev. 1 © 2013 Cyan, Inc. – All Rights Reserved. Page 59
LAD-2P, LAD-4, LAD-4A, LAD-8, LAD-8i, LAD-8A, LAD-8E, LAD-8X Add/Drop Ports
LAD-2P
LAD-4
LAD-4A
LAD-8
LAD-8i
LAD-8A
LAD-8E
LAD-8X
Wavelength
(nm)
ITU Channel
1 1 1 1553.33 30
2 2 2 1552.52 31
3 3 1551.72 32
4 4 1550.92 33
5 1549.32 35
6 1548.51 36
7 1547.72 37
8 1546.92 38
LAD-40, LAD-40E Add/Drop Ports
LAD-40
LAD-40E
Wavelength
(nm)
ITU Channel
LAD-40
LAD-40E
Wavelength
(nm)
ITU Channel
1 1560.61 21 21 1544.53 41
2 1559.79 22 22 1543.73 42
3 1558.98 23 23 1542.94 43
4 1558.17 24 24 1542.14 44
5 1557.36 25 25 1541.35 45
6 1556.55 26 26 1540.56 46
7 1555.75 27 27 1539.77 47
8 1554.94 28 28 1538.98 48
9 1554.13 29 29 1538.19 49
10 1553.33 30 30 1537.40 50
11 1552.52 31 31 1536.61 51
12 1551.72 32 32 1535.82 52
13 1550.92 33 33 1535.04 53
14 1550.12 34 34 1534.25 54
15 1549.32 35 35 1533.47 55
16 1548.51 36 36 1532.68 56
17 1547.72 37 37 1531.90 57
18 1546.92 38 38 1531.12 58
19 1546.12 39 39 1530.33 59
20 1545.32 40 40 1529.55 60
